Balanced Analog Inputs |
Dual (female) XLR jacks; switchable (high / low) input range; 18 dBu / 10 dBu |
Unbalanced Analog Inputs |
Dual RCA jacks; switchable (high / low) input range; 5.0 Vrms / 2.1 Vrms |
USB Digital Input |
Type B jack; USB 2.0; accepts digital audio formats up to 32-bit / 384 kHz PCM and DSD (DSD64/DSD128/DSD256) via DoP or Native |
Network (Ethernet LAN) Digital Input |
RJ45 jack; DLNA-compatible; accepts digital audio formats up to 32-bit / 384 kHz PCM and DSD (DSD64/DSD128/DSD256) via DoP or Native |
AES3 (AES/EBU) Digital Input |
XLR (female) jack; accepts digital audio formats up to 24-bit/192 kHz PCM |
S/PDIF Coaxial Digital Input |
RCA jack; accepts digital audio formats up to 24-bit/192 kHz PCM |
Line Outputs |
Balanced and unbalanced, high current outputs; +5 dB gain; switchable |
Digital Formats |
PCM: 16-32 bit / up to 384 kHz; DSD: up to 256 fs DoP and Native |
Digital Signal Processing (DSP) |
64-bit (double-precision) fixed-point processing at native sample rates |
Switchable Gain |
Rear panel switch; high level / low level selection for balanced analog input (professional audio and consumer levels) and unbalance analog input |
Source Selection |
Multi-position front panel selector with indicator LEDs for all sources |
Level Control |
Front panel, 31-position; digital and analog domain volume control (HP & Line Out) |
Status Display |
Front panel, 51 mm, full color, QVGA, TFT LCD (240 x 320 pixels) |
Display Functions |
Digital readout and bar graph of volume control setting; display of digital audio data format; display of rear panel analog input (gain) settings; display of Ethernet and USB data link transmission lock; display of detected fault modes and output clipping |
Auto Fault Detection |
Automatic detection, display and protection for: output amplifier clipping, unplugged connections and malfunctioning wiring, over-temperature conditions and internal electrical faults |
DACs |
2 x dual mono, 32-bit / 384 kHz DACs with balanced outputs, for PCM & DSD inputs |
Amplifier/Energizer |
Balanced, discrete MOSFET, high-bias, single-ended Class A output; dual mono topology, including power supply; 1800 VDC bias (charge) voltage |
Distortion + Noise |
< 0.001% |
Bandwidth |
> 65 kHz |
Enclosure |
CNC-machined 6063 aluminium; earth-grounded |
Power Supply |
External: world voltage compatible (90-264 Volt AC, 50-60 Hz); 24 Volt DC, 200 VA (8.333 A), fixed frequency, class B-compliant SMPS
Internal: isolated, dual mono; switching and ultra-low-noise linear regulation |
AC Mains |
Types B, G, F, I; IEC-60320 C14, earth- grounded power cable; 1.5 meter length |
Dimensions |
H x W x D: 68 mm (2.68 in.) x 413 mm (16.26 in.) x 351 mm (13.82 in.) |
Weight |
7.4 kg (16.28 lbs.), without Power Supply |
